Stratasys FDM 2000 - Page 145

Reference
Appendix M1
M1-5
®
10MAY01
Speed inches/sec
(maximum)
(recommended)
Road Height
(maximum)
(minimum)
(recommended)
Road Width
(maximum)
(minimum)
Liquefier Temp °C
(maximum)
(minimum)
(recommended)
Envelope Temp °C
(maximum)
(minimum)
(recommended)
Room Temp
°F
(maximum)
FDM Tip Inner Diameter
FDM System
Parameters
P400 - Plastic Material ABS
FDM 1600, 1650, 2000, 3000, and 8000
0.025"
0.012"
0.800
0.800
0.016"
0.004"
0.010"
0.040"
0.012"
270
270
See Spool
70
70
70
82
0.800
0.800
0.020"
0.010"
0.012"
0.060"
0.030"
270
270
See Spool
70
70
70
82
It is recommended to use the parameter values indicated
in bold for perimeter roads. The values in this table
may also be applied to fill and support roads if desired.
Unnotched Impact (ft*lb/in): ---
Elongation (%): 50.00
Hardness (Shore D): R105
Softening Point (R&B) (F): 220
Specific Gravity (GMS/CM
3
): 1.05
Tensile Strength (psi): 5,000
Flexural Strength (psi): 9,500
Tensile Modulus (psi): 360,000
Flexural Modulus (psi): 380,000
Notched Impact (ft*lb/in): 2.00
Material Specifications*
* Material specifications are based on ASTM tests.
1600, 1650
0.010"
2000/3000/8000
0.012"
0.016"
1.000
1.000
0.010"
0.007"
0.007"
0.030"
0.010"
290
290
See Spool
70
50
60
82
1.000
1.000
0.012"
0.007"
0.010"
0.040"
0.012"
270
270
See Spool
70
70
70
82
1.500
1.000 - 1.5000
0.014"
0.010"
0.010"
0.040"
0.016"
270
270
See Spool
70
70
70
82
