Stratus SAE-C10C - Page 12

12
Serial
number
Name Photo Parameter Quanty
18 Plasc cable e 15
19 Main column upper limit switch 1
20 Main column upper limit switch xing screw
Phillips round head screws M5×10L
2
21 Upper limit plate and limit switch
M4×10 and M4×25
1
22 Upper limit board 1
23 Upper limit plate xing screw
Hexagon Screw M10×20L
Each 4
24 Two cross arm connecng screws
Hexagon Screw M8×20L
Each 6
25 Two-secon cross arm end xing screws
Hexagon Screw M10×25L
Each 8
26
Heightening secon and column connecng
screw
Hexagon socket screws M10×16L
Each 12
27 Heightening secon buckle cover xing screw
Phillips round head screws M6×10L
Each 12
28 Cross beam connecng plate xing screw Hexagon socket screws M10×20L Each 8
29 Block rubber cover 2
30
Locking and unlocking rope seat assembly
accessories
2
31 Plasc buckle cover xing screw
Phillips round head screws M6×8L
8
32 User’s manual 1
