Stratus SAE-C10C - 10-Structure and Parts List; Main Column

29
10-Structure and Parts List
10.1-Main column
No. Name Qty. No. Name Qty.
1 Main column assembly 1 11 Height adaptor bracket 1
2 Power unit 1 12 Height adaptor 4
3 Power unit motor basement 1 13
Cross round head screw M8×10
2
4 Flat gasket Φ10 2 14 Main column longer oil cover 1
5 Spring washer Φ10 2 15
Cross round head screw M6×8
3
6
Inner Hexagon screw M10×16
2 16 Main column lock cover 1
7
Hex. Screw M8×20
4 17
Cross round head screw M6×8
4
8 Flat gasket Φ8 4 18 Main column shorter oil cover 1
9 Spring washer Φ8 4 19
Cross round head screw M6×8
2
10 Hex. Nut M8 4
