30
10.2 Vice column
No. Name Qty.
1 Slave column assembly 1
2 Height adaptor bracket 1
3 Height adaptor 4
4
Cross round head screw M8×10
2
5 Slave column longer oil cover 1
6
Cross round head screw M6×8
3
7 Slave column lock cover 1
8
Cross round head screw M6×8
4
9 Slave column shorter oil cover 1
10
Cross round head screw M6×8
2
