39
Specifications
Input Connector Antenna IEC 169-2 Female
Output Connector – RF Loop Out IEC 162-2 Male
Frequency range 174MHz–230MHz, 474MHz–868MHz
Input impedance 75Ω
IF bandwidth 7 and 8 MHz (switchable)
Code Rate 1/2, 2/3, 3/4, 5/6, 7/8
Tuner
& Channel Decoder
Guard Interval 1/4, 1/8, 1/16, 1/32
Standard MPEG-2 MP@L4.0 1920 × 1080 @ 50MHz
MPEG Transport
Stream
Rate 64 Mbps
Profile Level MPEG-2 MP@L4.0 1920 × 1080 @ 50MHz
Input Rate 80 Mbps
Aspect Ratio 4:3, Letter Box, 16:9, Pan & Scan
Video Decoding
Video Resolution 1080i, 720p, 576p, 576i
Standard MPEG Layer 1,2, 3; Dolby AC-3, 12S S/PDIF
Audio Decoding
Channels
Single, Dual Mono, Stereo, Joint Stereo, Dolby
Digital bit-streams
Main Processor ARM926
Main System
Memory
4Mb Flash; 64Mb SDRAM
HDMI
HDMI 1.2 connector ((with HDCP copy
protection)
Video Component Y / Pb / Pr Component YUV
Video SVHS 4-pin Din Connector
Video Composite RCA/Cinch, Video Output (CVBS)
S/PDIF Optical Digital Audio Output
Audio & Video
In/Out
USB USB 2.0
Input Voltage 100–240V AC
Power Consumption 20W maximum
Protection Seprate internal fuse
Power Supply
Type Switch-mode
Dimensions
W250mm x H38mm x D175mm (case
only)/185mm (to end of connectors)
Weight 1.9 kg
Physical
Optimum operating temperature 0–50°C
