Recycling Diagram
5
3
2
4
6
1
Item Material Qty. Comments
1 PC Board 1 —
2 Touchscreen LCD 1 —
3 PC Board 1 Not shown above; behind
touchscreen LCD
4 PC Board 1 —
5 PC Board 1 —
6 Power Supply 1 —
7 AC power cord 1 Not shown above
8 USB A-to-A cable 1 Not shown above
