9
Console Features
The features of the L10 AIM Light Source are described below.
Front Panel
54
3
2
1
1. Power Button Powers the unit on and o
2. IRIS Connectors For connecting the light source ends of the
IRIS Ureteral Kit (0220-180-518). Location of
Class 1 laser emissions when IRIS Ureteral
Kit is connected and IRIS mode is activated.
3. Touchscreen Provides user controls and system
feedback
4. Light Cable Connection For connecting the light-source end of
the light cable. Location of Class 1M laser
emissions when AIM SafeLight cable is
connected and ENV mode is activated.
5. Jaw Handle Opens and closes the clamp in the light
cable connection
