FFiigguurree 99 –– SSaaffeettyy bbaarr sseeccuurreedd iinn tthhee vveehhiiccllee ssaaffeettyy hhooookk
A
B
C
DE
FFiigguurree 1100 –– VVeehhiiccllee ssaaffeettyy hhooookk ppllaacceemmeenntt
A Top view of vehicle
B Vehicle safety hook
C Squad bench
D Bumper
E Door frame
After installation, make sure that the cot legs lock into the load position without contacting the vehicle bumper.
6516-209-001 Rev D.0 21 EN
