Stryker Power-PRO IT Cot - Installing the charger onto the optional mounting bracket

A
B
FFiigguurree 2288 –– MMoouunnttiinngg bbrraacckkeett
IInnssttaalllliinngg tthhee cchhaarrggeerr oonnttoo tthhee ooppttiioonnaall mmoouunnttiinngg bbrraacckkeett
To install the SSMMRRTT charger onto the optional mounting bracket (Figure 29):
1. Align the rear keyway slots (A) onto the bracket fasteners (B).
2. Slide the SSMMRRTT charger (C) in until it locks into the mounting bracket (D) to secure the charger to the bracket.
EN 44 6516-209-001 Rev D.0
