PPoowweerr ttyyppee OOppeerraattiioonnaall
vvoollttaaggee rraannggee
FFrreeqquueennccyy MMaaxxiimmuumm
ccuurrrreenntt ddrraaww
SSttaannddbbyy ccuurrrreenntt
ddrraaww
LLooww vvoollttaaggee
sshhuuttooffff
AC 100 to 240 VAC 50/60 Hz 1.20 A 0.05 A N/A
DC 12.5 to 16 VDC N/A 4.16 A 0.20 A 10 VDC
IInnssttaalllliinngg tthhee SSMMRRTT cchhaarrggeerr
When installing the SSMMRRTT charger, place the SSMMRRTT charger in an environmentally controlled location that is:
• Free of excessive dust and moisture
• Kept within a constant temperature range. An allowable temperature range is 43 °F to 88 °F (6 °C to 31 °C). The optimal
temperature range is 65 °F to 75 °F (18 °C to 24 °C).
• Readily accessed for use
Locate and maintain the power supply and power cords to minimize the risk of damage and inadvertent disconnections.
IInnssttaalllliinngg tthhee ooppttiioonnaall mmoouunnttiinngg bbrraacckkeett
WWAARRNNIINNGG
• Always have a certified mechanic, familiar with ambulance vehicle construction, install the optional mounting bracket
and the SSMMRRTT charger.
• Always mount the SSMMRRTT charger to the optional mounting bracket in an enclosed cabinet and out of patient reach
during transport to comply with established crash test standards.
• Always make sure that the optional mounting bracket is securely attached to the surface.
To install the optional mounting bracket (Figure 28):
1. Use the SSMMRRTT charger mounting bracket as a template to mark the location of the mounting holes (A) at the area where
you will install the mounting bracket.
2. Position the mounting bracket, making sure that the:
a. Spring tab (B) is located at the rear of the SSMMRRTT charger.
NNoottee -- When mounting the bracket to a vertical surface, the spring tab should be horizontal with the spring tab point
to the left (Figure 28).
b. Power cord easily plugs into the rear of the SSMMRRTT charger.
c. SSMMRRTT charger slides from front to back to connect to the bracket after mounting.
d. Bracket is installed correctly for the ambulance or station location:
AAmmbbuullaannccee llooccaattiioonn SSttaattiioonn llooccaattiioonn
• Secure the bracket to a horizontal structural support
surface or shelf using size #10, grade 5 screws
minimum (not supplied).
• Make sure that the selected mounting surface is strong
enough to securely hold the SSMMRRTT charger and SSMMRRTT
Pak during transport.
• Locate the bracket in an enclosed cabinet and out of
patient reach during transport.
• Allow for easy SSMMRRTT Pak installation and removal.
• Locate the power supply within reach of the power cord.
• Secure the bracket to a horizontal or vertical structural
support surface using size #10, grade 5 screws
minimum (not supplied).
• For vertical installation, position the mounting bracket
so the spring tab is directly below the mounting screws,
so the SSMMRRTT Pak remains supported by the SSMMRRTT
charger even if the release button is accidently pressed.
• Allow for easy SSMMRRTT Pak installation and removal.
• Locate the power supply within reach of the power cord.
