CChhaannggiinngg lleevveellss RRoolllliinngg LLooaaddiinngg aanndd uunnllooaaddiinngg
Two operators (O)
Two helpers (H)
Two operators (O)
Four helpers (H)
EExxtteennddiinngg tthhee rreettrraaccttaabbllee hheeaadd sseeccttiioonn
Extend the retractable head section before you load the cot into the vehicle patient compartment.
WWAARRNNIINNGG
• Always lock the head section into place before you operate the cot.
• Do not load the cot into a vehicle with the head section retracted when using a cot fastener. The cot may tip or not
connect with the cot fastener.
To extend the retractable head section:
1. Grasp the outer rail with one hand for support and pull the head section release handle. Rotate the head section release
handle toward the head end of the cot to release the head section from the locked position.
2. Release the head section release handle, then pull the head section away from the litter frame. Lengthen the head
section to the extended position.
3. Release the head section release handle to lock the head section in the extended position.
RReettrraaccttiinngg tthhee rreettrraaccttaabbllee hheeaadd sseeccttiioonn
Retract the retractable head section to roll the cot in any direction on the load wheels for improved mobility and
maneuverability, even in the lowest position.
WWAARRNNIINNGG
• Always lock the head section into place before you operate the cot.
• Do not load the cot into a vehicle with the head section retracted when using a cot fastener. The cot may tip or not
connect with the cot fastener.
To retract the retractable head section:
1. Grasp the outer rail with one hand for support and release the head section release handle. Rotate the head section
release handle toward the head end of the cot to release the head section from the locked position.
6516-209-001 Rev D.0 31 EN
