TimeLine - User Manual
®
pg 4
POWER: NEVER
plug into voltage
higher than
9VDC. Requires
at least 300mA of
available current.
9V DC center
negative polarity.
INPUTS
: High
impedance inputs.
Use LEFT input
for mono. RIGHT
IN is used as an
effect return if the
feedback loop is
selected.
OUTPUTS: Use
LEFT output for
mono. RIGHT
OUT is used as an
effect send if the
feedback loop is
selected.
Rear Panel
EXP: Connect
an expression
pedal or switch
for external tap
tempo. See EXP
Connections.
LOOP SWITCH: Set switch to feedback loop to
insert an effect in the delay feedback path. See
Feedback Loop.
MIDI: Full featured MIDI input and output
supporting MIDI CCs, Program changes, etc. See
the MIDI Specification section for a complete list of
features and commands.
