Electrical Systems Operation & Diagnosis Module (602)
The PRG Auto Closer is located in place of the conventional rear gate latch assembly. The PRG
Auto Closer is equipped with the following components:
- Rear gate latch
- Gate latch motor
- Sector switch
- Courtesy and Latch Switch
NOTE: The PRG Auto Closer functions in normal PRG operations and manual mode.
NOTE: If a problem with the Sector Switch or Courtesy and Latch Switch exists, the
PRG will not fully latch. The rear gate will try to fully close but the PRG control
unit will sound a long beep and the gate will move away from the rear gate
latch. The rear gate cannot be opened until pushed completely closed and the
opener button is then pressed and held for more than 3 seconds.
PRG Auto Closer
Auto Closer Bottom View Auto Closer Top View
