Sumitomo Drive Technologies Cyclo 6000 - 8.3.6 Long Term Shutdown;Storage; 8.4 Grease Replenishment for Grease Lubricated Units; 8.4.1 Grease Replenishment Intervals

A. Grease Quantities for Unit Overhaul
Table A-1a: Grease Change (Overhaul) Quantities for Maintenance-Free Speed Reducers
Table A-1b: Grease Change (Overhaul) Quantities for Non-Maintenance-Free Speed Reducers
Frame Size 606X 607X 608X 609X 610X 611X 612X 606XDA 607XDA 609XDA 610XDA 612XDA 612XDB
Speed
Reduction
Mechanism
(1st stage)
0.9
(25)
0.9
(25)
1.4
(40)
2.1
(60)
4.2
(120)
6.7
(190)
8.8
(250)
0.9
(25)
0.9
(25)
0.9
(25)
0.9
(25)
0.9
(25)
2.1
(60)
Speed
Reduction
Mechanism
(2nd stage)
0.9
(25)
0.9
(25)
2.1
(60)
4.2
(120)
8.8
(250)
8.8
(250)
Slow Speed
Shaft Bearing
0.5
(15)
0.5
(15)
0.9
(25)
1.1
(30)
1.1
(30)
1.6
(45)
1.9
(55)
0.5
(15)
0.5
(15)
1.1
(30)
1.1
(30)
1.9
(55)
1.9
(55)
X = 0 or 5
X = 0 or 5
oz. (g)
oz. (g)
Frame Size 613XDA 613XDB 613XDC 614XDA 614XDB 614XDC 616XDA 616XDB 616XDC 617XDA 617XDB 617XDC
Speed Reduction
Mechanism
(1st stage)
0.9
(25)
2.1
(60)
4.2
(120)
0.9
(25)
2.1
(60)
4.2
(120)
2.1
(60)
4.2
(120)
8.8
(250)
2.1
(60)
4.2
(120)
8.8
(250)
Speed Reduction
Mechanism
(2nd stage)
15.9
(450)
15.9
(450)
15.9
(450)
15.9
(450)
15.9
(450)
15.9
(450)
26.5
(750)
26.5
(750)
26.5
(750)
35.3
(1000)
35.3
(1000)
35.3
(1000)
Slow Speed Shaft
Bearing
10.6
(300)
10.6
(300)
10.6
(300)
10.6
(300)
10.6
(300)
10.6
(300)
10.6
(300)
10.6
(300)
10.6
(300)
17.6
(500)
17.6
(500)
17.6
(500)
Frame Size 618XDA 618XDB 619XDA 619XDB 6205DA 6205DB 6215DA 6215DB 6225DA 6225DB 6235DA 6235DB
Speed Reduction
Mechanism
(1st stage)
4.2
(120)
15.9
(450)
11.6
(330)
15.9
(450)
11.6
(330)
15.9
(450)
15.9
(450)
26.5
(750)
15.9
(450)
35.3
(1000)
26.5
(750)
38.8
(1100)
Speed Reduction
Mechanism
(2nd stage)
38.8
(1100)
38.8
(1100)
52.9
(1500)
52.9
(1500)
52.9
(1500)
52.9
(1500)
70.5
(2000)
70.5
(2000)
88.2
(2500)
88.2
(2500)
141.1
(4000)
141.1
(4000)
Slow Speed Shaft
Bearing
21.2
(600)
21.2
(600)
24.7
(700)
24.7
(700)
24.7
(700)
24.7
(700)
28.2
(800)
28.2
(800)
31.7
(900)
31.7
(900)
35.3
(1000)
35.3
(1000)
Frame Size 6245DA 6245DB 6255DA 6255DB 6265DA
Speed Reduction
Mechanism
(1st stage)
26.5
(750)
38.8
(1100)
35.3
(1000)
52.9
(1500)
52.9
(1500)
Speed Reduction
Mechanism
(2nd stage)
158.7
(4500)
158.7
(4500)
211.6
(6000)
211.6
(6000)
282.2
(8000)
Slow Speed Shaft
Bearing
38.8
(1100)
38.8
(1100)
42.3
(1200)
42.3
(1200)
45.9
(1300)
www.SumitomoDrive.com
Cyclo® 6000 Operating and Maintenance Manual
Cyclo® 6000 Cyclo® 6000
Cyclo® 6000 Operating and Maintenance Manual
92 93
APPENDIX APPENDIX
Table A-1c: Grease Change (Overhaul) Quantities for Normally Oil-Lubricated Speed Reducers Supplied With Grease.
Frame Size
6130
6135
6140
6145
6160
6165
6170
6175
6180
6185
6190
6195
6215 6225 6235 6245 6255 6265
Speed Reduction
Mechanism
15.9
(450)
26.5
(750)
35.3
(1000)
36.8
(1100)
52.9
(1500)
70.5
(2000)
88.2
(2500)
141.1
(4000)
158.7
(4500)
211.6
(6000)
282.2
(8000)
Slow Speed Shaft
Bearing
10.6
(300)
10.6
(300)
17.6
(500)
21.2
(600)
24.7
(700)
28.2
(800)
31.7
(900)
35.3
(1000)
36.8
(1100)
42.3
(1200)
45.9
(1300)
NOTE: Grease ll quantities in Table A-1c are used when a unit that is normally oil-lubricated is supplied with grease.
