Sumitomo Drive Technologies Cyclo 6000 - 8.3 Oil Quantities and Oil Change for Oil Lubricated Units; 8.3.1 Oil Change Interval; 8.3.2 Approved Lubricating Oils; 8.3.3 Oil Fill Quantities

Table 8-8: Lubricating Oil Inspection and Change Intervals
Table 8-11: Oil Fill Quantities
Table 8-10: Allowable Oil Lubricant Viscosity
Change Interval Operating Condition
Oil Supply Time of Purchase -
Oil Change
First Time After 500 hours or 6 months, whichever comes rst. -
2nd. and Subsequent Times
Every 5,000 hours, or every year, whichever comes rst. Indoors, etc. at 0 to 35 °C
Every 2,500 hours, or every 6 months, whichever comes rst.
Outdoors or hot locations, etc., where 0 to 35 °C cannot
be maintained.
Minimum Allowable
Viscosity
For oil temperature during operation, minimum 15mm
2
/S. Viscosity that will obtain required lm strength under load.
Maximum Allowable
Viscosity
Oil Bath Lubricated Models Maximum 4,300mm
2
/S Viscosity at which Cyclo Drive can start.
Force Feed Lubricated Models Maximum 2,200mm
2
/S Viscosity at which the plunger pump and motorized trochoid pump can start.
Note: Oil degrades more rapidly when ambient temperature is high or changes radically, and when corrosive gases
are present. In such cases consult with the lubricating oil manufacturer.
Always use lubricating oils approved by Sumitomo Machine Corporation of America as shown in Table 8-9.
Table 8-9: Approved Oils
ExxonMobil: Spartan EP Shell Oil: Omala S2 G Kluber: Kluberoil GEM1
ExxonMobil: Mobilgear 600XP Caltex: Meropa Idemitsu Oil: Daphane Mechanic
ExxonMobil: Mobil SHC Gear Hi-Shock 150 Castrol: Alpha SP BP Oil: Energol GR-XP
Food Grade Oil: Klübersynth UH1 6-460 Gulf Oil: EP Lubricant HD Total: Carter EP
° F 14 32 50 68 86 104 122
° C -10 0 10 20 30 40 50
ISO VG
68
(14 °F to 41 °F)
100/150
(32 °F to 95 °F)
220/320/460
(86 °F to 122 °F)
Notes:
1. When using in winter or where the ambient temperature is relatively low, use an oil with a viscosity at the
lower end of the range.
2. For allowable lubricating oil viscosity see Table 8-10. Use within this required viscosity range.
3. For a smooth startup use oil with a pour point at least 5°C below ambient temperature.
4. If operating temperature changes within a wide range use a high viscosity index oil that meets requirements in
Notes 2 and 3.
5. Please consult factory if regularly operating outside the ambient temperature range of 0 to 40°C, as some parts of the
mechanism may need to be changed, and lubricating oil might need to be preheated, or cooled.
Cyclo Horizontal Foot Mounted / Cyclo Horizotal V-Flange Mounted
Size 613X 614X 616X 617X 618X 619X 6205 6215 6225 6235 6245 6255 6265 6275
US gal 0.18 0.18 0.37 0.50 0.66 1.1 1.5 2.2 2.6 4.0 4.2 5.5 7.7 14.8
liter 0.7 0.7 1.4 1.9 2.5 4 5.5 8.5 10 15 16 21 29 56
Size 616XDC 617XDC 618XDB 619XDA 619XDB 6205DA 6205DB 6215DA 6215DB 6225DA 6225DB 6235DA 6235DB 6245DA
US gal 0.40 0.63 0.92 1.5 1.6 1.6 1.6 2.6 2.6 2.9 2.9 4.5 4.5 4.8
liter 1.5 2.4 3.5 5.8 6
6 6 10 10 11 11 17 17 18
Size 6245DB 6255DA 6255DB 6265DA 6275DA
US gal 4.8 6.1 6.1 8.5 15.9
liter 18 23 23 32 60
Cyclo Vertical V-Flange Mounted
Size 613X 614X 616X 617X 618X 619X 6205 6215 6225 6235 6245 6255 6265 6275
US gal 0.29 0.29 0.26 0.50 0.53 0.71 1.5 2.0 2.6 3.2 4.0 11.1 13.5 (15.9)
liter 1.1 1.1 1 1.9 2 2.7 5.7 7.5 10 12 15 42 51 (60)
Size 616XDC 617XDC 618XDB 619XDA 619XDB 6205DA 6205DB 6215DA 6215DB 6225DA 6225DB 6235DA 6235DB 6245DA
US gal 0.26 0.50 0.53 0.71 0.71 2.9 2.9 3.7 3.7 4.8 4.8 6.1 6.1 7.7
liter 1 1.9 2 2.7 2.7
11 11 14 14 18 18 23 23 29
Size 6245DB 6255DA 6255DB 6265DA 6275DA
US gal 7.7 11.1 11.1 13.5 (15.85)
liter 29 42 42 51 (60.00)
Cyclo Horizontal Flange Mounted
Size 613X 614X 616X 617X 618X 619X 6205 6215 6225 6235 6245 6255 6265 6275
US gal 0.07 0.07 0.24 0.34 0.40 0.53 0.79 1.1 1.3 2.0 2.1 2.9 3.7 7.9
liter 0.25 0.25 0.9 1.3 1.5 2 3 4 5 7.5 8 11 14 30
Size 616XDC 617XDC 618XDB 619XDA 619XDB 6205DA 6205DB 6215DA 6215DB 6225DA 6225DB 6235DA 6235DB 6245DA
US gal 0.26 0.53 0.61 1.0 1.1 1.1 1.1 1.5 1.5 1.6 1.6 2.5 2.5 2.6
liter 1 2 2.3 3.8
4 4 4 5.5 5.5 6 6 9.5 9.5 10
Size 6245DB 6255DA 6255DB 6265DA
US gal 2.6 3.4 3.4 4.5
liter 10 13 13 17
X = 0 or 5 ( ) = With Trochoid Pump
www.SumitomoDrive.com
Cyclo® 6000 Operating and Maintenance Manual
Cyclo® 6000 Cyclo® 6000
Cyclo® 6000 Operating and Maintenance Manual
42 43
8.3 Oil Quantities and Oil Change for Oil Lubricated Units
8.3.1 Oil Change Interval
8.3.3 Oil Fill Quantities
8.3.2 Approved Lubricating Oils
8. DAILY INSPECTION AND MAINTENANCE 8. DAILY INSPECTION AND MAINTENANCE
