Sumitomo Bevel Buddybox 4 User Manual

Manual BBB4_ENG_01_2016_991301 3
Important Notes
Explosive gas mixtures or dust concentrations combined with hot, live and moving parts on the gears may
cause serious or fatal injuries.
Installing, connecting, commissioning and maintaining and repairing the gearbox and additional electrical
equipment must only be carried out by a qualied professional, taking account of
- these instructions
- the warning and instruction plates on the gearbox
- any other development documents and connection diagrams relating to the drive
- the plant-specic conditions and requirements
- the national and regional standards and regulations in force (explosion protection, safety, accident protection).
The gears are designed for industrial plants and must only be used in accordance with the information in the
technical documentation from Sumitomo and the data on the model plate. They comply with the standards and
regulations in force and meet the requirements of Directive 94/9EG.
A drive motor connected to the gearbox must only be started up after ensuring that the measures set out in the
section Motor Installation have been carried out before installation.
A motor connected to the gearbox may only be operated on the frequency inverter if the information on the
gearbox rating plate is obeyed.
The consignment must be checked immediately after receipt for any transport damage. The carrier must
be notied of this immediately. If it must be assumed that transport damage will restrict proper operation
then the unit must not be started up.
Only prescribed slings of the correct size that can be hooked into the existing eyebolts or can be put round the
ange connections must be used. The screwed in eyebolts are only designed for the weight of the drive. No
additional loads must be suspended.
Do not allow the unit to drop or fall while moving. Always use the eye bolts attached to the gear housing (and
on motor if supplied) when moving the unit. After securing the unit to the machine, remove the moving hooks/
straps from the eyebolts.
Before working on the machine (assembling, operating, maintaining, inspecting etc.), please read these operating
instructions through carefully so that you know exactly how to operate the gearbox properly, you know the safety
regulations to be applied and the warnings to be heeded. Keep these instructions near by the machine so that you
can refer to them at any time if necessary.
Transport, installation, lubrication, operation, maintenance and inspections should only be carried out by pro-
perly trained technicians, otherwise injury or damage to the machine may result.
Keep hands and all foreign objects away from the internal moving parts of the unit, otherwise injury or damage
to the machine may occur.
The gearbox unit must be put out of action and disconnected from the power supply for maintenance and
assembly work.
The unit must only be used for the intended purpose, otherwise there is the risk of injury or damage to the
machine.
Safety notes
Notes on transport
Safety instructions for use in an ATEX area
Ex
