Sumitomo Bevel Buddybox 4 User Manual

34 Manual BBB4_ENG_01_2016_991301
1
Identify the bevel portion oil fill plug on the bevel gear housing. Carefully remove
the plug and put aside for reinsertion after oil fill is complete.
2
Fill the bevel portion with the appropriate type and grade of oil.
The bevel portion is considered full when the oil level reaches the oil fill port.
Oncelliscomplete,re-installandtightentheoilplugintothellport
Y2 Oil Fill & Drain Procedures
Oil Fill Process
Affected Unit Sizes
This document is intended for all Bevel Buddybox (BBB) 4 series
units built in the Y2 mounting (motor up) configuration. Images
contained within the document show a single reduction input
stage,howevertheprocessremainsthesamefordoubleandtriple
reduction product offerings.
Oil Fill Process
CAUTIONARYNOTE:
•UseonlythoselubricatingoilsapprovedbySumitomoDriveTechnologiesforuseintheBevelBuddybox.
•Usetheappropriategradeoflubricatingoilbasedonambientoperatingconditionsoftheapplication.
•RefertotheSumitomoproductcatalogand/orOperating&MaintenancemanualforalistofSumitomoapprovedlubricatingoils.
•Priortobeginningthellprocess,ensuretheUnitDrainPlugisinplaceandadequatelytightened.
Por
tion
F l
C p
F
ill Plug
F l
Bevel
Cu
