Sumitomo Bevel Buddybox 4 User Manual

Manual BBB4_ENG_01_2016_991301 5
Important Notes
Inspection Upon Delivery
• Inordertoavoidinjury,ensure that the unit is
in a stable position before unpacking.
• Verify that the unit received matches your
order. Using the incorrect product may cause
equipmentdamageorpersonalinjury.
• Do not remove the nameplate from the unit.
Upondelivery,inspecttheunitfordamagethatmayhave
occurred during shipment. Notify the shipping company
immediately if you find any damage. Do not install or operate a
damaged unit.
Uponreceiptofthereducer/gearmotor,verifythat:
• themodelnumberontheunitnameplatematchesthe
purchase order
• theunitwasnotdamagedduringshipping
• allboltsandnutsarefullytightened.
PleaseconsultyourSumitomoagent,distributor,orsalesoce
if you find any defects or if you have any questions.
Nameplate Inspection
WhencontactingSumitomoaboutthisproduct,pleasebe
prepared to provide the following information from the
reducer/gearmotornameplate:
• reducerorgearmotormodelnumber(nomenclature)
• reductionratio
• serialnumber.
Lubrication Inspection
• Oil lubricated units are shipped without oil,
unless the customer specified otherwise when
the unit was ordered. Always fill the unit with
the correct type and quantity of lubricant prior to
operation.
• Certain models must be filled with lubricant
in two separate locations, the Bevel Gear
portion (output) and the input portion.
Refer to the lubrication section in this manual for detailed
lubrication information.
Input Speed Lubrication
Unit Model
Number
Unit Serial
Number
Year of
Manufacture
Service Factor
Input Power
Nominal
Reduction Ratio
Output Torque
Standard Nameplate

Sumitomo Bevel Buddybox 4 Specifications

General

Brand	Sumitomo
Model	Bevel Buddybox 4
Category	Engine
Language	English
