5-2
5. Heater program｜Heater program list
5. Heater program
The applicable fiber protection sleeves vary depending on the cleave length. Below
are examples of protection sleeves.
■ Protection sleeves
Category Heater program Details
Drop cable
60mm Drop
Can be used for heat shrinking 60mm protection sleeves for drop
cable splice, for example, Sumitomo FPS-D60.
40mm Drop
Can be used for heat shrinking 40mm protection sleeves for drop
cable splice.
Splice-On
Connector
LYNX
Can be used for heat shrinking protection sleeves for 10mm cleaved
Sumitomo’s splice-on-connector “Lynx-CustomFit™”.
E-SC Fusion
Can be used for heat shrinking dedicated protection sleeves for
Sumitomo “E-SC Fusion Connector”.
LYNX MINI
Can be used for heat shrinking protection sleeves for 5mm cleaved
Sumitomo’s splice-on-connector “Lynx-CustomFit™”.
Others
25mm 0.4
Can be used for heat shrinking 25mm protection sleeves of Nano
Sleeves N4 series, for example, Sumitomo FPS-N4-25.
20mm 0.4
Can be used for heat shrinking 20mm protection sleeves of Nano
Sleeves N4 series, for example, Sumitomo FPS-N4-20.
25mm 0.9
Can be used for heat shrinking 25mm protection sleeves of Nano
Sleeves N9 series, for example, Sumitomo FPS-N9-25.
20mm 0.9
Can be used for heat shrinking 20mm protection sleeves of Nano
Sleeves N9 series, for example, Sumitomo FPS-N9-20.
45mm Thin
Can be used for heat shrinking 45mm semi-shrunk protection
sleeves for single fiber, for example, SPS-45.
Protection
Sleeve
Sleeve Length
[mm]
Diameter After
shrink [mm]
Coating Diameter
[mm]
Recommended
Cleave length
[mm]
FPS-1 60.5 Approx.3.2 0.25 to 0.9 16
FPS-40 40.5 Approx.3.2 0.25 to 0.9 10
FPS-61-2.6 61.5 Approx.2.6 0.25 to 0.9 16
FPS-D60 60.5 Approx.4.5×4.7
Drop/Indoor cable
2.0×3.1(o
2.6)
1.6×2.0
10
