Controls and Indicators
12 SL500 User’s Guide • July 2008 Revision: KA • 96116
FIGURE 1-3 Buttons and Indicators
1. Door Open button 5. Service Required LED
2. Door Open LED 6. Library Active LED
3. CAP Open button 7. Service Robot LED
4. CAP Open LED
TABLE 1-5 Keypad Buttons and Indicators
Buttons/Indicator Description
Service Robot Indicator
LED is lit when the robot is not functioning.
The service representative might need to check the log_error
file for the result code and perform the appropriate action.
Library Active Indicator
LED is active when the library is active.
1324
57
6
L204
014
