Appendix A Connector Signal Descriptions 209
16 Gnd Ground
17 TERMPOWER Termpower
18 TERMPOWER Termpower
19 NC Not connected
20 Gnd Ground
21 Gnd Ground
22 Gnd Ground
23 Gnd Ground
24 Gnd Ground
25 Gnd Ground
26 Gnd Ground
27 Gnd Ground
28 Gnd Ground
29 Gnd Ground
30 Gnd Ground
31 Gnd Ground
32 Gnd Ground
33 Gnd Ground
34 Gnd Ground
35 SCSI_B_DAT<12> Data 12
36 SCSI_B_DAT<13>_ Data 13
37 SCSI_B_DAT<14>_ Data 14
38 SCSI_B_DAT<15>_ Data 15
39 SCSI_B_PAR<l> Parity 1
40 SCSI_B_DAT<0>_ Data 0
41 SCSI_B_DAT<1>_ Data 1
42 SCSI_B_DAT<2>_ Data 2
43 SCSI_B_DAT<3>_ Data 3
Pin Signal Name Description
To Next Page
