210 Sun Fire 280R Server Owner’s Guide • January 2001
44 SCSI_B_DAT<4> Data 4
45 SCSI_B_DAT<5> Data 5
46 SCSI_B_DAT<6> Data 6
47 SCSI_B_DAT<7> Data 7
48 SCSI_B_PAR<0> Parity 0
49 Gnd Ground
50 NC Not connected
51 TERMPOWER_B Terminal B Power
52 TERMPOWER_B Terminal B Power
53 NC Not connected
54 Gnd Ground
55 SCSI_B_ATN_L Attention
56 Gnd Ground
57 SCSI_B-BSY_L Busy
58 SCSI_B_ACK_L Acknowledge
59 SCSI_B_RESET_L Reset
60 SCSI_B_MSG_L Message
61 SCSI_B_SEL_L Select
62 SCSI_B-CD_L Command
63 SCSI_B_REQ_L Request
64 SCSI_B_IO_L In/out
65 SCSI_B_DAT<8> Data 8
Pin Signal Name Description
