4 Mechanical Mounting User Manual
16
3. Do not install the inverter in the living area or bedrooms. The noise
during its operation may affect daily life.
4. The location should be not accessible to children.
5. The ambient temperature and relative humidity should meet the following
requirements.
Max.
+60°C
Min.
-25°C
Max. RH
+100%
6. Only mount the inverter on a non-flammable surface or a wooden
structure. Keep away from flammable materials or gas. Do not enclose
the inverter into a tight confinement.
Enclosed cabinet
Flammable wall
Flammable material or
gas near the installation
7. The shaded side of the building would be better to prevent the inverter
from exposure to the sun, rain, and snow.
8. Install at eye level for easy
9. Install vertically for good heat
dissipation.
10. Never install the inverter horizontally, or with a forward tilt or with a
backward tilt or even with upside down. The horizontal installation can
result in damage to the inverter.
