This item is operated by the factory only, so general users and A/S technicians should not use it.
No. Function StepInitial value
If an output signal has been sent twice in the OUTPUT00~OUTPUT15 output pin, the same signal will appear in two different output pins.
Ex) if OUTPUT00 = 0 & OUTPUT03 = 0, then B/T signal is output from both OUTPUT00 & OUTPUT03 pin
When setting up other functions apart from the function numbers listed above, the pertinent output pin functions are disregarded.
Roller Lift Solenoid = Presser Foot-Lift solenoid + Back Tack solenoid + Roller Lift Switch
[ Caution ]
If the specific items of the parameter are changed carelessly, they could break down or damage the machine, so the user must be
well-trained before using it.
30 OUTPUT00 (B/T Solenoid) : Low Active 0(Fixed)
31 OUTPUT01 (P/F Solenoid) : Low Active 1(Fixed)
32 OUTPUT02 (T/T Solenoid) : Low Active 2
33 OUTPUT03 (W/P Solenoid) : Low Active 3
34 OUTPUT04 (T/R Solenoid) : Low Active 4
35 OUTPUT05 (Left Solenoid) : Low Active 5
36 OUTPUT06 (Right Solenoid) : Low Active 6
37 OUTPUT07 (AUX Solenoid) : Low Active 7
38 OUTPUT10 (Left LED) : High Active 8
39 OUTPUT11 (Right LED) : High Active 9
40 OUTPUT12 (Needle upper stop notifying signal) : High Active 10
41 OUTPUT13 (Needle lower stop notifying signal) : High Active 11
42 OUTPUT14 (Signal notifying motor is running) : High Active 12
43 OUTPUT15 (Signal notifying target has been reached) : High Active 13
44~ NOT USED
49 NOT USED
Output port changing function
- write the function number on
the output PIN you want to
change after referring to the
table below
A : Output PIN function
Function No.
0 B/T Solenoid (with duty) 100 inv. B/T Solenoid (with duty)
1 P/F Solenoid (with duty) 101 inv. P/F Solenoid (with duty)
2 T/T Solenoid (with duty) 102 inv. T/T Solenoid (with duty)
3 W/P Solenoid (with duty) 103 inv. W/P Solenoid (with duty)
4 T/R Solenoid (with duty) 104 inv. T/R Solenoid (with duty)
5 Left Solenoid (with duty) 105 inv. Left Solenoid (with duty)
6 Right Solenoid (with duty) 106 inv. Right Solenoid (with duty)
7 AUX Solenoid (with duty) 107 inv. AUX Solenoid (with duty)
8 Left LED (with duty) 108 inv. Left LED (with duty)
9 Right LED (with duty) 109 inv. Right LED (with duty)
10
Needle Up-stop notifying signal (with duty) 110 inv. Needle Up-Stopped (with duty)
11 “Needle Down-stop”notifying signal (with duty) 111 inv. Needle Down-Stopped (with duty)
12 “Sewing machine running”notifying signal (with duty) 112 inv. Motor Running (with duty)
13 “Target speed”notifying signal (with duty) 113 inv. Target Speed (with duty)
14 “Trimming”notifying signal (without duty) 114 inv. Trimming (without duty)
15 "End Back Tack" notifying signal (without duty) 115 inv. End Back Tack (without duty)
16 “Emergency stop”notifiying signal (without duty) 116 inv. Emergency Stopped (without duty)
- A signal appears when the motor stops for any error. -A signal appears when the motor stops for any error
17 Roller Lift Solenoid (without duty) 117 inv. Roller Lift Solenoid (without duty)
18 Hemming Device Output (without duty) 118 inv. Hemming Device Output (without duty)
19
First step forward pedal notifying signal (without duty) 119 inv. Pedal Start (without duty)
200 Low signal (without duty) 201 High signal (without duty)
H/W type actual output name H/W type actual output name
Function No.
