10
Control box back (Full Option Type)Control box front (Full Option Type)
1) Front and back of control box
AC Power switch
AC Power Input Power Cable
Control box grounding part
Option 2 Connector
Pedal Connector
Encoder Connector
Motor Power Connector
Position Detector Connector
P/U Connector
Option 1 Connector
A/B Button Connector
Solenoids Connector
Option 3
Button
A/B
Option1
Option3
S/M
Synchro
P/U
Motor
Encoder
Pedal
Option2
SUNSTAR ELECTRIC CO., LTD.
Control box back (Economic Type)Control box front (Economic Type)
AC Power switch
Simple Controller Board
AC Power Input Power Cable
Control box grounding part
Option 2 Connector
Pedal Connector
Encoder Connector
Motor Power Connector
Position Detector Connector
P/U Connector
Option 1 Connector
A/B Button Connector
Solenoids Connector
Button
A/B
Option1
S/M
Synchro
P/U
Motor
Encoder
Pedal
Option2
SUNSTAR ELECTRIC CO., LTD.
