No. Function StepInitial value
Caution : When any inputs PIN No. INPUT00 INPUT22 are overlapped, it works as the "OR" circuit.
Ex) if INPUT00 = 0 & INPUT01 = 0, then it is recognized as “button A”= INPUT00 + INPUT01.
The hardware of input switches and sensors are done with “a point of contact/Active High”input as the standard.
When setting up other functions numbers apart from the ones listed above, the pertinent output pin functions are disregarded.
[ Caution ]
If the specific items of the parameter are changed carelessly, they could break down or damage the machine, so the user must be
well-trained before using it.
50 INPUT00 (Button A) 0
51 INPUT01 (Button B) 1
52 INPUT02 (1/4 stitch Switch) 2
53 INPUT03 (2/4 stitch Switch) 3
54 INPUT04 (3/4 stitch Switch) 4
55 INPUT05 (4/4 stitch Switch) 5
56 INPUT06 (Left Sol. Switch) 6
57 INPUT07 (Right Sol. Switch) 7
58 INPUT10 (Presser Foot-Lift Switch) 8
59 INPUT11 (Counter Switch) 9
60 INPUT12 (P/U 1/2 stitch Switch Signal) 10
61 INPUT13 (Safety Switch Signal) 11
62 INPUT14 (Edge Sensor Signal) 12
63 INPUT15 (Thread trimmer not allowed Signal) 13
64 INPUT20 (Pedal Start Signal) 16
65 INPUT21 (Pedal Presser Foot-Lift Signal) 17
66 INPUT22 (Pedal Trim Signal) 18
70 Output Signal Level Collective Reverse Function 0 0/1
1=Output signa Collective Reverse¸ selection
71 Input Signal Level Collective Reverse Function 0 0/1
1=Input signal Collective Reverse¸ selection
72~ NOT USED
99 NOT USED
Output port changing function
- Write the function number
on the output PIN you want
to change after referring to
the table below
B : Input PIN function
No.
0 Button A Switch 100 inv Button A Switch
1 Button B Switch 101 inv Button B Switch
2 1/4 stitch Switch 102 inv 1/4 stitch Switch
3 2/4 stitch Switch 103 inv 2/4 stitch Switch
4 3/4 stitch Switch 104 inv 3/4 stitch Switch
5 4/4 stitch Switch 105 inv 4/4 stitch Switch
6 Left Solenoid Switch 106 inv Left Solenoid Switch
7 Right Solenoid Switch 107 inv Right Solenoid Switch
8 Presser Foot-Lift Switch 108 inv Presser Foot-Lift Switch
9 Counter Switch 109 inv Counter Switch
10 Program Unit 1/2 stitch Switch 110 inv Program Unit 1/2 stitch Switch
11 Safety Switch 111 inv Safety Switch
12 Edge Sensor Signal 112 inv Edge Sensor Signal
13 Thread Trimmer Signal 113 inv Trimming Disabled Signal
14 Roller Lift Switch 114 inv Roller Lift Switch
15 N_AUTO Switch 115 inv N_AUTO Switch
16 Pedal Start Signal 116 inv Pedal Start Signal
17 Pedal Presser Foot-Lift Signal 117 inv Pedal Presser Foot-Lift Signal
18 Pedal Thread Trimming Signal 118 inv Pedal Thread Trimming Signal
19 External Signal 119 inv External Signal
20 Machine-Head-Open Switch 120 inv Machine-Head-Open Switch
Actual Hardware Output Name Actual Hardware Output NameNo.
