69
(4) Thread Trimming Sequence Program Code List
Category
3rd2nd1st
Data Field
Cmd FieldExplanation
B/T Solenoid On 81H
P/F Solenoid On 82H
T/T Solenoid On 83H
W/P Solenoid On 84H
T/R Solenoid On 85H
Left Solenoid On 86H
Right Solenoid On 87H
AUX Solenoid On 88H
Left LED On 89H
Right LED On 8AH
Needle Up Signal On 8BH
Needle Down Signal On 8CH
Motor Runing Signal On 8DH
Reaching Target Speed Signal On 8EH
Motor Trimming Signal On 8FH
Motor End Tacking Signal On 90H
Emergency Stop Signal On 91H
Roller Lift Solenoid On 92H
Hemming Device Output On 93H
Pedal Forward Step1 Signal On 94H
B/T Solenoid Off 98H
P/F Solenoid Off 99H
T/T Solenoid Off 9AH
W/P Solenoid Off 9BH
T/R Solenoid Off 9CH
Left Solenoid Off 9DH
Right Solenoid Off 9EH
AUX Solenoid Off 9FH
Left LED Off A0H
Right LED Off A1H
Needle Up Signal Off A2H
Needle Down Signal Off A3H
Motor Runing Signal Off A4H
Reaching Target Speed Signal Off A5H
Motor Trimming Signal Off A6H
Motor End Tacking Signal Off A7H
Emergency Stop Signal Off A8H
Roller Lift Solenoid Off A9H
Hemming Device Outout Off AAH
Pedal Forward Step1 Signal Off ABH
Delay by 1[ms] unit B0H
0~255[ms]
(1ms)
Delay by 2[ms] unit B1H
0~510[ms]
(2ms)
Delay by 4[ms] unit B2H
0~1020[ms]
(4ms)
Delay by 0.5[s] unit B3H
0~127.5[s]
(0.5s)
Output
Port
Control
(Total 40)
Time Delay
To Next Page
