51
2) Fortuna Series 4 Full Function Software Specific Parameters
(1) Group A Parameter: General functions of sewing machine
[ Caution ]
If the specific items of the parameter are changed carelessly, they could cause breakdown or damage the machine. Therefore,
the user must be well-trained before using it.
No. Function StepRange
Initial value
1 Minimum speed of pedal (limit of sewing machine's minimum speed) 200spm 20~510 2spm
2 Maximum speed of pedal (limit of sewing machine's maximum speed) 4000spm 40~9960 40spm
3
Thread trimmer speed
300spm 20~510 2spm
(Sewing machine speed from beginning to end of thread trimming when using CAM type)
4 Program Unit + 1 stitch speed ( Key's performance speed) 100spm 20~510 2spm
5 Lifting of needle plate with button A, dropping speed ( 's performance speed) 300spm 20~510 2spm
Pedal degree of acceleration (Pedal Curve)
6 255 1~255 1
( ;When the maximum speed is put in 255 steps)
7 Start Back-Tack Speed 1700spm 20~2000 10spm
8 End Back-Tack Speed 1700spm 20~2000 10spm
Thread trimming operation time (When doing an aging test,
9 (The A24 used in PNEUMATIC = must be 1) 100ms 4~1020 the value is equal to the running time)
(The Solenoid operation time)
10 Tension release operation time (The A24 used in PNEUMATIC = must be 1) 200ms 4~1020
(When doing an aging test, the value
is equal to the thread trimming time)
11
Tension release time (In CAM type, the used A24 = must be 0)
255 0~255
(In CAM type, the tension release is the value of the moving CAM angle)
12
Waiting time for the next operation after thread trimming
4ms 4~1020
(This is the delaying time to carry out the next operation after thread trimming is finished)
13 Wiper operation time (Wiper Solenoid operating time) 48ms 4~1020 4ms
14 Waiting time after wiper operation(presser foot-lift etc.) 40ms 4~1020 4ms
15 Automatic presser foot-lift delaying time 100ms 4~1020 4ms
16
Automatic presser foot- lift maintaining time
(After programmed time the presser foot-lift is automatically released)
300
0.1sec 5~1000 0.5sec
Automatic presser foot-lift drop waiting time for next operation
17 (The delaying time, or the time that the foot-presser lift is maintained, 100ms 4~1020 4ms
the pedal is started until the presser foot-lift drops and the sewing machine is started)
18 Selection for automatic foot-presser lift after thread trimming
0 0/1 1=lift selection
0=2step backward thread trimming
19 Selection for pedal thread trimming position
0 0/1/2 1=1 step backward thread trimming
2=thread trimming at neutral position
20
The maximum sewing speed for the KM-1060BL-7 presser foot-lift
2000spm 200~2000 10spm
with mutual crossing quantity of 4.8~7.0[mm]
21 Delaying time for complete release of KM-1060BL-7 B/T Solenoid 200ms 4~1020ms 4ms
Select to operate 2 start B/T
22 0 0/1 Choose between 1 or 2
()
Select to operate 2 end B/T
23 0 0/1 Choose between 1 or 2
()
To Next Page
