12
The sewing pulley is turned clockwise when seeing from the end of the pulley.
1) OIL
Mobil Velocite Oil No. 10(ISO Viscosity Grade 22)
55
66
LUBRICATION
DIRECTION OF PULLEY ROTATION
Check the OFF-status condition of a power switch before lubricating.
Warning
Do not put foreign substances into the lubricating oil to prevent oil from aging of and breaking
down.
Caution
We recommend that you operate the sewing machine at the rate of 4,000 s.p.m for 200hours
(about a month) for the durability.
The direction of the main shaft pulley① and the motor pulley② rotation is clockwise.
Caution
[Figure 4] [Figure 5]
①
②
To Next Page
