WATER RECYCLING SYSTEM
Publication: 0028607 5-7
5
2. Slowly loosen the T-handle (3) at the strainer cap (4)
and allow the Y-strainer to drain.
Figure 5-12
3. Remove the Y-strainer cap. Remove and clean the
filter element (5).
Figure 5-13
4. Reverse the procedure to install the filter element.
• If you are jetting with clean water only, the fine Y-filter
element (6) should be used.
• If you are jetting using the recycle feature, the course
Y-filter element (7) should be used.
Figure 5-14
