Super Products Camel 1200 (Ejector Unloading) - Page 54

1-44 Publication: 0028607
SAFETY
1
Figure 1-49
Figure 1-50
Figure 1-51
Figure 1-52
Figure 1-53
Figure 1-54
Figure 1-55
Figure 1-56
Part no. 3050-00033
Part no. 3050-00024
Part no. 3050-00572
Part no. 0007448
3050-00024
DRAIN HERE
WATER SUPPLY
ON/OFF
WARNING
DO NOT GO UNDER A RAISED BODY UNLESS
THE BODY SUPPORT IS USED. FAILURE TO DO
SO COULD RESULT IN DEATH OR SERIOUS
INJURY.
BODY SUPPORT OPERATION
TO USE:
1. CONFIRM BODY IS UNLOADED BEFORE USING SUPPORT.
2. RAISE BODY SUFFICIENTLY TO ALLOW SUPPORT TO BE SWUNG INTO POSITION.
3. SWING BODY SUPPORT INTO SUPPORT POSITION.
4. VISUALLY CONFIRM THAT SUPPORT IS SECURE BEFORE PERFORMING ANY WORK.
TO STORE:
1. RAISE BODY SLIGHTLY.
2. RETURN SUPPORT TO TRANSIT POSITION
Part no. 0026476
Part no. 3050-00338
Part no. 3050-00337
Part no. 3050-00578
3050-00338
CLOSED
OPEN
3050-00337
