SELECTING THE PROPER LOCATION FOR
YOUR CONTROLLER
Indoor Wall Mount
If possible, always select an indoor location for your controller where you are
assured of maximum protection from environmental hazards, accidents, and van-
dalism. Mount the controller on a solid, smooth surface shoulder high so the
operator can easily see the display and read the faceplate graphics.
Outdoor Wall Mount
The most desirable location is shoulder high on the shady side of a suitable wall.
Avoid concealing the controller behind a shrub or near ground level where it will
be in the direct path of a sprinkler head.
MOUNTING THE CONTROLLER
Wall Mount
Select suitable fasteners such as molly bolts in plaster board, wood screws in
wood, etc. Check to see that the head of the screw will pass through the keyhole
slot in the rear of the case. Use the enclosed template to locate mounting screw
holes.
If additional support is desired, remove lower plate on the enclosure by removing
the screws that hold each side and mount one additional fastener through the
lower hole in rear of housing.
Pedestal Mount
If the unit is to be mounted on a pedestal, follow instructions supplied with the
pedestal.
