SuperMax SUPERBRUSH 36 - Parts List for Stand

28 SUPERBRUSH OWNER’S MANUAL
Ref. Description Part Number Qty./
Number SB24 Both SB36 Unit
Models
1 HANDLE, SWIVEL ASSY 31-0020 2
2 PIN, ROLL 3/16X1 20-0772 2
3 WASHER, 5/8 I.D. OILITE 50-3080 4
4 RING, 5/8 RETAINING 20-0752 1
5 SUPPORT, ADJUSTING SCREW 30-1112 8
6 SCREW, 1/4-20x1/2 SOCKET HEAD SET 10-2804 12
7 SCREW, INBOARD HEIGHT ADJ. FOLLOW 30-1211HR 1
8 CAP, 1” PLASTIC 80-4013 2
9 GEAR, MITER 20-1101 4
10 BUSHING, 1/2 I.D. OILITE ROUND 50-3107 4
11A RPM, BRACKET 40-0670 1
11B RPM, DECAL (NOT SHOWN) 94-1674 1
12 COLLAR, 1/2 I.D. SHAFT 20-1103 2
13 TUBE, COLUMN 30-3044 2
14 SCREW, RPM, MOTOR 30-1209 1
15 MOUNT, MOTOR 30-5103 1
16 NUT, 5/16-18 HEX 12-0003 6
17 WASHER, 5/16 SAE 11-0206 8
18 SCREW, 5/16-18x3/4 BRASS TIPPED SET 10-9906 6
19 BOLT, 3/8-16x1-1/2 HEX HEAD 10-9207 8
20 WASHER, 5/16 WROUGHT 11-9103 20
21 BOLT, 3/8-16x1 HEX HEAD 10-9205 12
22 NUT, 3/8-16 HEX 12-0005 8
23 LEVELING FOOT 20-0655 4
24 SCREW, OUTBOARD HEIGHT ADJ. 30-1212HR 1
25 NUT, 3/8-16 FLANGE LOCK 12-0209 24
26 BASE, COLUMN 30-1101 2
27 BASE SUPPORT BRACKET 40-0230 40-4241 1
28 NUT, 5/8-11HEAVY HEX LOCK 12-8015 1
29 SCREW, 1/2-13x1/2 SOCKET HEAD SET 10-8905 2
30 ROD, TRANSFER 30-1213 30-3117 1
31 SUPPORT BRUSH 30-5206 2
32 BOLT, 3/8-16x1 1/4 HEX 10-9206 4
33 SUPPORT, OUTBOARD TABLE 30-5204 1
34A DEPTH GAUGE ROD 30-1260HR ROD 1
34B DECAL, SCALE 94-1654 SCALE 1
35 NUT, 9/16-12 HEX 12-0011 2
36 LEG 30-1102 4
37 KNOB, LOCKING W/ SET SCREW 81-3132 2
38 CAP, 3Y PLASTIC COLUMN TUBE 80-4015 2
39 SCREW, 5/16-18x3/8 SOCKET HEAD SET 10-2903 4
40 MOTOR MOUNT 40-0106 1
41 SUPPORT, INBOARD TABLE 30-5205 1
42 BRACKET, TABLE MOUNT 40-0025 40-0037 2
CLIP, FRAME (NOT SHOWN) 72-6208 1
BUSHING, 1/2 I.D. OILITE ROUND (NOT SHOWN) 50-3110 2
SUPERBRUSH STAND ASSEMBLY PARTS LIST
