SuperMax SUPERBRUSH 36 - Parts List for Conveyor Assembly

32 SUPERBRUSH OWNER’S MANUAL
SUPERBRUSH CONVEYOR & MOTOR PARTS LIST
Ref. Description Part Number Qty./
Number SB24 Both SB36 Unit
Models
1 1/4˝-20x1/2˝ ROUND HEAD MACH SCREW 10-3205 3
2 WASHER, 1/4 INTERNAL TOOTH LOCK 11-0504 3
3 SWITCH BRACKET 40-5005 1
4 SWITCH BOX 72-5400-2 1
5 ON/OFF SWITCH 72-5400-1 1
6 1/4˝-20 HEX NUT 12-0001 3
7 LARGE STRAIN RELIEF 72-6104 4
8 CORD SET, SINGLE PHASE, 32˝ 72-5315 1
CORD SET, THREE PHASE, 32˝ 72-5305 1
9 CONTROLLER, 180 V, VARIABLE SPEED 72-1260 1
INCLUDING KNOB, NUT AND DIAL PLATE
10 SMALL STRAIN RELIEF 72-6102 1
11 FUSE HOLDER 72-6202 1
12 180-VOLT GEAR MOTOR 71-1171 1
13 CORD SET, MAIN W/PLUG, SINGLE PHASE 72-5430 1
CORD SET, MAIN, NO PLUG, THREE PHASE 72-5305 1
14 V-BELT 50-2029 1
15 RETAINING CLIP 72-6210 1
16 5/16˝-18x3/8˝ SOCKET HEAD SET SCREW 10-2903 1
17 CORD SET, SINGLE PHASE, 66˝ 72-5315 1
CORD SET, THREE PHASE, 66˝ 72-5305 1
18 KEY STOCK, 1/4x1 3/4 N/A 1
19 FUSE, 3/4 AMP 72-6201 1
21 PULLEY, DRIVE, VARIABLE SPEED 50-0704 1
22 #10-24 RETAINING NUT 20-1157 2
23 LOWER INNER BELT GUARD 40-1000 1
24 5/16˝-18 FLANGED LOCK NUT 12-0207 4
25 3/8˝ WROUGHT WASHER 11-0104 2
26 MOTOR, 5 HP. TEFC, SINGLE PHASE 71-0502 1
MOTOR, 5 HP. TEFC, THREE PHASE 71-1503 1
27 5/16˝-18x3/4˝ CARRIAGE BOLT 10-1203 4
28 5/16˝-18x1/2˝ HEX HEAD BOLT 10-9101 4
29 CONTROL HOUSING 40-5012 1
30 5/16˝-18 RETAINING NUT 20-1159 4
31 SCREW, 5/16-18x1/4 SOCKET HEAD SET SCREW 10-8902 2
32 COUPLING (CONVEYOR) 30-3102 1
33 CONTROL BOX BASE BRACKET 40-4115 1
34 #10-24x3/8˝ SLOTTED HEX HEAD SCREW 10-3803 2
35 #10-24 RETAINING NUT 20-1155 2
36 BOTTOM COVER 40-4116 1
37 RIGHT SIDE RAIL 40-4106 1
