30 SUPERBRUSH OWNER’S MANUAL
Ref.
Description Part Number
Qty./
Number SB24 Both SB36 Unit
Models
1 DUST COVER 40-0655 40-3655 1
2 HANDLE, DUST COVER 80-2841 1
3 BOLT, HEX 3/8-16X1 10-9205 8
4 WASHER, 5/16 SAE 11-0206 8
5 BRACKET, BEARING MOUNTING (see Fig. 25) 40-0613 2
6 BEARING 50-3086 2
7 SCREW, 1/4-20x1/4 SOCKET HEAD SET 10-8802 4
8 BOLT, 5/16-18x3/4 CARRIAGE 10-1203 8
9 PULLEY, 7˝ (TYPICAL) 50-0701 1
10 SCREW, 5/16-18x3/8 SOCKET HEAD SET 10-8903 1
11 NUT, 3/8-16 FLANGE LOCK 12-0209 8
12 KEY STOCK, 1/4x1/4x1 1/4 20-0764 1
13 SCREW, 1/4-20x1 3/4 ROUND HEAD MACHINE 10-3213 4
14 BRACKET, LEFT SUSPENSION 40-0323 2
15 SPRING, TENSION ROLLER 20-3284 4
16 BRACKET, RIGHT SUSPENSION 40-0326 2
17 BUSHING, 1/2 ID OILITE ROUND 50-3107 4
18 BRACKET, SUSPENSION BASE 40-0322 2
19 NUT, 1/4-20 RETAINING 20-1153 4
21 ROLLER TENSION 30-1218 30-3218 2
22 NUT, 5/16-18 FLANGE LOCK 12-0207 6
23 HINGE 40-0225 3
24 BRACKET, DUST COVER MOUNTING 40-0605 40-3605 1
25 SCREW, 1/4-20x1/2 ROUND HEAD MACH 10-3205 12
26 WASHER, 1/4 INTERNAL TOOTH LOCK 11-0504 12
27 SCREW, 8x1/2 SELF TAPPING 10-3904 2
28 WASHER, 1/4 SAE 11-0205 12
29 NUT, 1/4-20 HEX 12-0001 12
30 NUT 5/16-18 WING 12-9050 4
31 WASHER, 5/16 INTERNAL TOOTH LOCK 11-0505 4
32 BUMPER, DUST COVER 80-1065 2
33 GUARD, BELT COVER 40-0009 1
34 GUARD, BELT, PLATE 40-0010 1
35 GUARD, BELT LOWER 40-0011 1
36 GUARD, BELT, ANGLED 40-0012 1
37 NUT, RETAINING 20-1155 6
38 NUT, RETAINING 20-1157 4
39 SCREW, 10-24x3/8 SLOTTED HEX HEAD 10-3803 10
40 BRUSH See page 35 1
SUPERBRUSH HEAD ASSEMBLY PARTS LIST
