34 SUPERBRUSH OWNER’S MANUAL
SUPERBRUSH CONVEYOR & MOTOR PARTS LIST (Con’t.)
Ref.
Description Part Number
Qty./
Number SB24 Both SB36 Unit
Models
38 1/2˝ I.D. SQUARE OILITE BUSHING 50-3109 4
39 RUBBER COVERED DRIVE ROLLER 30-3106 30-3107 1
40 3/8˝ FLANGED LOCK NUT 12-0209 16
41 LEFT SIDE RAIL 40-4105 1
42 ROLLER SUPPORT BRACKET 40-4109 1
43 3/8˝-16x3/4˝ CARRIAGE BOLT 10-1301 4
44 3/8˝-16x1” CARRIAGE BOLT 10-1302 16
45 5/16˝-24 FLANGE NUT 12-0308 6
46 5/15˝-24x3˝ STUD 30-1306 2
47 TAKE-UP BASE BRACKET 40-4107 2
48 5/16˝ SAE WASHER 11-0206 4
49 WRENCH 40-0375 2
50 TAKEUP SLIDE 40-4108 2
51 DRIVEN ROLLER 30-3103 30-3104 1
52 3/8˝ SPRING WASHER 20-1165 4
53 3/8˝-16 NYLON INSERT LOCK NUT 12-8005 4
54 CONVEYOR BED 40-4101 40-4201 1
55 CONVEYOR BELT (NOT SHOWN) 61-1004 61-1007 1
