(of 100% Pulse Width Modulation Duty Cycle) for maximum cooling. This setting

is recommended for special system conguration or debugging. Select "Standard"

for the onboard fans to run at 50% of the Initial PWM Cycle in order to balance the

needs between system cooling and power saving. This setting is recommended

for regular systems with normal hardware congurations. Select "Optimal" for the

onboard fans to run at 30% of the Initial PWM Cycle for best power efciency and

maximum quietness. The options are Full Speed (@100% of PWM Cycle), Standard

(@50% of PWM Cycle), and Optimal (@30% of PWM Cycle).

CPU Temperature Display Mode

This feature displays the CPU temperature detected by DTS (i.e., +34

C) or tem-

perature status in text ("Low", "Medium" or "High"). The options are Text Mode

or DTS.

If Text Mode is selected, the CPU Temperature Display Mode will show the CPU

temperature status as follows:

Low – This level is considered as the ‘normal’ operating state. The CPU

temperature is well below the CPU ‘Temperature Tolerance’. The mother-

board fans and CPU will run normally as congured in the BIOS (Fan Speed

Control).

User intervention: No action required.

Medium – The processor is running warmer. This is a ‘precautionary’ level

and generally means that there may be factors contributing to this condition,

but the CPU is still within its normal operating state and below the CPU

‘Temperature Tolerance’. The motherboard fans and CPU will run normally

as congured in the BIOS. The fans may adjust to a faster speed depending

on the Fan Speed Control settings.

User intervention: No action is required. However, consider checking the CPU

fans and the chassis ventilation for blockage.

High – The processor is running hot. This is a ‘caution’ level since the CPU’s

‘Temperature Tolerance’ has been reached (or has been exceeded) and may

activate an overheat alarm:

The information provided above is for your reference only. For more information

on thermal management, please refer to Intel’s Web site at www.Intel.com.

Fan1 ~ Fan5 Reading

This feature displays the fan speed readings from fan interfaces Fan1 through

Fan4 and FanA.

VIN0, VIN1, VIN2, VIN3, AVCC, 3VCC, VSB3, VBAT

This feature displays the current voltages of the above voltage monitors.
