1-6
C7Q67 User’s Manual
Motherboard Features
CPU Single 2nd generation Intel Intel® Core™ i7/i5/i3 DT pro-
cessor in an LGA1155 socket.
Memory Four (4) SDRAM slots support up to 32 GB of DDR3 Unbuf-
fered, Non-ECC 1333/1066 memory
Supports dual-channel memory bus
DIMM sizes
UDIMM 1 GB, 2 GB, 4GB, and 8GB
Chipset Intel® Q67 Express
Expansion Slots One (1) PCI Express 2.0 x1 slot
One (1) PCI Express 2.0 x4 slot
One (1) PCI Express 2.0 x16 slot
One (1) PCI 33 MHz slots (5 Volts)
Network Connections Two (2) Gigabit Ethernet Controllers:
LAN1: Intel 82579LM PHY
LAN2: Intel 82574L
Two (2) RJ-45 Rear I/O Panel Connectors with Link and
Activity LEDs
I/O Devices SATA Connections
SATA 3.0 (6Gb/s) Two (2) (SATA 0~1)
SATA 2.0 (3Gb/s) Four (4) (SATA 2~5)
RAID (Windows) RAID 0, 1, 5, 10
RAID (Linux) RAID 0, 1, 10
USB Devices
Two (2) USB 3.0 ports on the rear I/O panel (USB 3.0 0/1)
Four (4) USB 2.0 ports on the rear I/O panel (USB 10/13,
USB 8/9)
Six (6) Front Accessible USB 2.0 ports on three headers
(USB 2/3, USB 4/5, USB 11/12)
Keyboard/Mouse
One shared PS/2 Keyboard/Mouse port on the I/O
backpanel
Serial (COM) Ports
Three (3) front accessible Serial Port headers (COM2,
COM3, COM4)
One (1) Serial Port on the back panel (COM1)
Audio
Five (5) Female Mini Jacks for High Denition Audio on
the Back Panel
