1-10
SUPER P4DC6/P4DC6+/P4DC6+II/P4DCE/P4DCE+/P4DCE+II User’s Manual
Motherboard Features
CPU
• P4DC6/P4DC6+/P4DCE/P4DCE+: Single or dual Intel
®
Xeon
TM
1.40 - 2.40
GHz
603-pin processors at a 400 MHz system bus speed
• P4DC6+II/P4DCE+II: Single or dual Intel
®
Xeon
TM
1.40 - 2.80 GHz
603-pin
processors at a 400 MHz system bus speed
Note: - refer to the motherboard specifications pages on our web site for updates on
supported processors (http://www.supermicro.com/Product_page/product-m.htm).
Memory
• Four PC600/800 RDRAM RIMM sockets to support up to 2 GB RDRAM
Chipset
• Intel
®
860 (82860NB)
• P64H (82806AA PCI-64 Hub)
• ICH2 (82801BA I/O CH, 82802AB Firmware Hub)
Expansion Slots
• One 4xAGP Pro (1.5v only)
• Two 64-bit PCI 66 MHz (3.3v)
• Four 32-bit PCI 33 MHz
BIOS
• 4 Mb Firmware Hub Award
®
Flash BIOS
• ACPI/APM Power Management
• PAC'99 color-coded I/O connectors
• Internal control of Power-On mode for recovery from AC power loss
PC Health Monitoring
• Nine onboard voltage monitors for two CPU core voltages, two CPU I/O
voltages, +3.3v, ±5v, ±12v, 3v battery, and 5v system bus
• Three-fan status monitor with firmware/software on/off control
• Environmental temperature monitor and control
• CPU fan auto-off in sleep mode
• Three CPU/chassis temperature monitors
• System overheat LED and control
• System resource alert
• Chassis intrusion detection
• Auto-switching voltage regulator for the CPU core
• Slow blinking LED for suspend state indicator
