2-16
SUPER P4DC6/P4DC6+/P4DC6+II/P4DCE/P4DCE+/P4DCE+II User's Manual
Keyboard Wake-Up
The JPWAKE jumper is used to-
gether with the Keyboard Wake-Up
function in BIOS. Enable both the
jumper and the BIOS setting to al-
low the system to be woken up by
depressing a key on the keyboard.
See Table 2-27 for jumper settings.
JPWAKE is located near the key-
board and mouse ports.
Note: Your power supply must
meet ATX specification 2.01 or
higher and supply 720mA of
standby power to use this feature.
Jumper
Position
1-2
2-3
Definition
Disabled
Enabled
Table 2-27
Keyboard Wake-Up
Jumper Settings
(JPWAKE)
USB Wake-Up
Jumper JP39 is used in conjunction
with the Keyboard Wake-Up func-
tion in BIOS when you wish to wake
the system up with a USB keyboard
that has been connected to a USB
port (not header). Set JP39 to pins
1-2 to support USB keyboard wake-
up and resume from ACPI S1 mode
and pins 2-3 pins to support USB
keyboard wake-up and resume
from ACPI S3 mode. See Table 2-
28 for jumper settings.
Note: Your power supply must pro-
vide 5v of standby voltage with at
least 1A to use this feature.
Jumper
Position
1-2
2-3
Definition
5v
5v Standby
Table 2-28
USB Wake-Up
Jumper Settings (JP39)
