Supero X9DRW-3LN4F+ - Motherboard Features

Chapter 2: Overview
1-7
Motherboard Features
CPU
• Dual Intel
®
E5-2600 Series (Socket R) processors;
each processor supports two full-width Intel Quick-
Path Interconnect (QPI) links (with support of up to
8.0 GT/s per QPI link and with Data Transfer Rate
of up to 16 GB/s direction peak bandwidth per port)
Memory
• Integrated memory controller supports:
1. 240-pin Registered (RDIMM)/Load Reduced
(LRDIMM) ECC or Unbuffered (UDIMM) ECC/Non-
ECC DDR3 800/1066/1333/1600 MHz memory
modules of up to 768 GB in 24 DIMM module slots
Note: For the latest CPU/memory updates,
please refer to our Website at http://www.su-
permicro.com/products/motherboard.
DIMM sizes
• RDIMM 1GB, 2GB, 4GB, 8GB,16GB and
32GB @ 1.35V/1.5V
• Virtualization: VT-x, VT-d, and VT-c
Chipset
• Intel® C606 PCH
Expansion
• One (1) SMC-Proprietary WIO-R slot (SXB2),
• One (1) SMC-Proprietary WIO-L slot
(SXB1A/1B/1C/1D)
Slots
Graphics
• Nuvoton BMC Video Controller
Network
• One Intel I350 Gigabit (100/1000 Mb/s) Ethernet
Dual-Channel Gb Controller for LAN1/LAN2 ports.
• One Intel I350/X540 10-Gigabit Ethernet Dual-Channel
Controller for LAN3/LAN4 ports (GLAN Ports for
-3LN4F+; 10GLAN Ports for -3TF+)
• Nuvoton Base-board Controller (BMC) supports
IPMI_LAN 2.0
I/O Devices
SATA Connections
• SATA Ports Six (6) SATA Ports:
Two (2) SATA 3.0 and
Four (4) SATA 2.0
• RAID RAID 0, 1, 5, 10
