X9DRW-3LN4F+/3TF+ Motherboard User’s Manual
SAS Connections
• C606 PCH SAS Controller
• SAS Ports 0~3, 4~7
• SCU Support RAID 0, 1, 10
IPMI 2.0
• IPMI 2.0 supported by the Nuvoton BMC
Serial (COM) Port
• Two (2) Fast UART 16550 Connection: 9-pin RS-
232 port
Keyboard/Mouse
• Backplane USB Keyboard/Mouse
VGA
• Backplane VGA Port
Peripheral
Devices
USB Devices
• Two (2) USB ports on the rear I/O panel (USB 0/1),
• Four (4) USB connections for front access (USB
2/3, USB 4/5),
• One (1) Type A USB connections for front access
(USB 6)
BIOS
• 16 MB AMI BIOS
®
Flash EEPROM
• APM 1.2, DMI 2.3, PCI 2.3, ACPI 1.0/2.0/3.0, USB
Keyboard, Plug & Play (PnP) and SMBIOS 2.3
Power
• ACPI/ACPM Power Management
Cong.
• Main switch override mechanism
• Intel® Manageability Engine (ME)
• Intel
®
Intelligent Power Node Manager (NM)
• Power-on mode for AC power recovery
• Advanced Power Management with NM and ME
support (Refer to Section 1-8)
PC Health
CPU Monitoring
Monitoring
• Onboard voltage monitors for MEM_AB, MEM_CD,
MEM_EF, MEM_GH, +3.3V, 3.3VSB, +5V, +5V
Standby, 12V and Battery Voltage.
• CPU 6-Phase switching voltage regulator
• CPU/System overheat LED and control
