Chapter 1: Introduction
1-7
*X9SCAA Only
Ports, Connectors, LED Indicators
Item # Connector Description
1
Back Panel I/O
See "Back Panel IO Connectors", page 2-8
2
AUDIO FP Front Panel Audio Header
4
SP/DIF OUT SP/DIF Digital Audio Header (Output)
5
SP/DIF IN SP/DIF Digital Audio Header (Input)
7
Mini PCIE* Mini PCI-E Expansion Slot
8
SLOT1 PCI-33MHz Expansion Slot (5V Key)
9,10,11,12
COM3*,1,4*,2 Internal Headers for COM1~4
13
USB 0/1 Internal Header for USB 0/1
14
USB 2/3* Internal Header for USB 2/3
15
JTPM1 TPM Header
16
JSD1 Disk-On-Module (DOM) Power Header
17
JP5 Reserved for GPIO Programming
18
JD1 External Speaker Header
19
JF1 Front Panel Controls Header
21
JOH1 Overheat Warning LED Header
23
J3 Auxilliary Power Output Header for Internal Devices
24
JPW2 4-Pin 12VDC Only Power Input
25
JPW1 24-Pin ATX Power Input
26
FAN1 CPU Fan Power/Control Header
27
CPU Intel Atom N2800 Series Processor
28
LVDS LVDS Port for VGA (Optional HDMI/Dual Display)
3,32
SATA1,SATA0 Internal SATA Ports
33
SP1 Internal Speaker/Buzzer
34,35 SODIMM1,SODIMM2 SODIMM Memory Slots
Item # LED Description Color/State Status
20
PWR Power LED
Green/Solid Power is On
22
Suspend
Suspend LED
Green/Blinking System in Suspend Mode
