X9SCAA Motherboard Series User's Manual
Motherboard Features
CPU Single Intel® ATOM N2800 Series Processor
Memory Two (2) SODIMM slots support up to 4GB of DDR3, unbuf-
fered, 1066 MHz, non-ECC SO-DIMM memory
Supports dual-channel memory bus
DIMM sizes
SODIMM 1GB, 2GB and 4GB
Chipset Intel® NM10 (2.1W)
Expansion Slots One (1) PCI-33MHz Expansion Slot
One Mini PCI-E Slot (full or half card) with mSATA
Graphics Intel GMA 3650
Network Connections Two (2) Intel 82574L
Two (2) RJ-45 Rear IO Panel Connectors with Link and
Activity LEDs
I/O Devices SATA Connections
SATA 2.0 Ports Two (2) (I-SATA0, I-SATA1)
USB Devices
X9SCAA
Two (2) USB 2.0 Ports on the back panel (USB 4/5)
Two (2) USB 3.0 Ports on the back panel (USB 6/7)
Four (4) USB Ports on two headers (USB 0/1, USB 2/3)
X9SCAA-L
Two (2) USB 2.0 Ports on the back panel (USB 4/5)
Four (4) USB Ports on two headers (USB 0/1)
HDMI Port (Back Panel)
X9SCAA only: One (1) HDMI port
VESA DisplayPort (Back Panel)
X9SCAA only: One (1) VESA DisplayPort
LVDS Header
One (1) LVDS Header
VGA Port (Back Panel)
One (1) Back panel VGA port
Audio Devices
One (1) Front Audio Mic/Headphone Header
Keyboard/Mouse
USB Keyboard/Mouse support
