Preface
About This Manual
This manual is written for system integrators, PC technicians and
knowledgeable PC users. It provides information for the installation and use of
the X9SCAA motherboard product series. This product is intended to be
professionally installed and serviced by a technician.
About This Motherboard
The X9SCAA motherboard series is a value-driven product aimed at users who
demand a reduced-cost, low-power motherboard for control board, network appli-
ance, thin client and many embedded applications.
The X9SCAA motherboard series comes with the Intel® ATOM N2800 CPU installed
and other features such as two SODIMM support, USB 2.0, VGA, and an on-board
LVDS. A VESA DisplayPort, HDMI port, an LVDS header, USB 3.0 and a Mini-PCIe
slot with mSATA are also supported on the X9SCAA. This enables the X9SCAA
motherboardseriestodeliveracost-effective,energyefcient,HDandrichmedia
solution in a mini-ITX form-factor.
Manual Organization
Chapter 1describesthefeatures,specicationsandperformanceofthemainboard
and provides detailed information about the chipset.
Chapter 2 provides hardware installation instructions. Read this chapter when in-
stalling the processor, memory modules and other hardware components into the
system. If you encounter any problems, see Chapter 3, which describes trouble-
shooting procedures for video, memory and system setup stored in the CMOS.
Chapter 4 includes an introduction to the BIOS and provides detailed information
on running the CMOS Setup utility.
Appendix A provides BIOS Error Beep Codes.
Appendix B lists Driver Installation Instructions.
Appendix C provides the UEFI BIOS Recovery Instructions.
