Serial Ports (COM1~4)
Four COM headers (COM1, COM2,
COM3*, COM4*) are located on the
motherboard. These are located next
to the PCI slot to provide front panel
access using a compatible cable (not
included). See the table on the right for
pin denitions.
Serial Ports
Pin Denitions
Pin # Denition Pin # Denition
1 DCD 6 DSR
2 RXD 7 RTS
3 TXD 8 CTS
4 DTR 9 RI
5 Ground 10 N/A
COM1
COM2
COM3*
COM4*
1
1
2
2
4
3
4
3
*X9SCAA only
*X9SCAA only
