Chapter 1: Introduction
1-9
Serial (COM) Ports
Up to four (4) fast UART 16550 connections
X9SCAA: Four (4) COM headers (COM1~4). COM3 with
RS422/RS485.
X9SCAA-L: Two (2) COM headers (COM1, COM2)
Super I/O
ITE IT8760E
BIOS 64 Mb SPI AMI BIOS
®
SM Flash BIOS
Play and Plug, ACPI 4.0, USB Keyboard and SMBIOS
2.7.1
Power ACPI/ACPM Power Management
Main Switch Override Mechanism
Suspend-To-RAM (STR)
One (1) Disk-On-Module (DOM) Power Connector
Power-on mode for AC power recovery
PC Health Monitoring One (1) 4-pin fan header
Watch Dog
Utilities (Download) BIOS ash upgrade utility
Drivers and software for Intel® NM10 chipset
Other ROHS 6/6 (Full Compliance, Lead Free)
One (1) TPM Header
Operating
Environment Operating Temperature Range: 0°C ~ 60°C (32°F ~ 140°F)
Non-Operating Temperature Range: -20°C ~ 70°C (-4°F ~ 158°F)
Operating Relative Humidity Range: 10% ~ 85% (non-condensing)
Non-Operating Relative Humidity Range:10% ~ 95% (non-condensing)
Dimensions Mini-ITX form factor (6.7" x 6.7"), 8-layers
