Supmeter BST100-B11 User Manual

11
3.4 Keypad Operation
If there is not any keypad operation in one minute and it‟s not in the processes of „F2 Calibration‟ & „F6 Factory
Adj.‟, the controller will return to „Main Display Interface‟ automatically.
3.4.1 Menu Operation
3.4.2 Quick Operation
*: Keep the key pressed for 2 seconds.
Key Name
Description
【MENU】
【ESC】
Enter Main Menu.
Exit.
【ENT】
Enter/Save.
【◄】
Cursor shifts left.
【►】
Cursor shifts right.
【▲】
Cursor shifts up.
Display the previous interface or option.
Digit input: +1.
【▼】
Cursor shifts down.
Display the next interface or option.
Digit input: -1.
Key Name
Description
【MENU】*
(【LOCK】)
 Key-locking.
 Key-unlocking.
【◄】
(【ADJ+】)
Control Current +1mA.
【►】
(【ADJ-】)
Control Current -1mA.
【◄】*
(【AUTO】)
„Manual/Auto‟ Control Mode Selection.
【►】*
(【EXT】)
„Internal/External‟ Flow Set Mode Selection.
【PRINT】
Print.
