21
4.3.3.3 Relay Switch Output (DO) to PLC Connection
PLC
Switch input with common source
IN1
IN2
V+
+24V
DOx+
DOx-
Controller
Controller
IN1
PLC
Switch input with common ground
IN2
COM
+24V
DOx+
DOx-
www.zemicusa.info
