6.3.2 Extra Scale Parameters (SCAL1)
No.
Sign
Parameter
Range
Default
Set
P110
-Cn-
Calibration Revolutions
1~99R (1R=1 Belt Length)
3
P111
CHAn
Chain Weight
0.1~1000.0kg/m
([P107] Scale Unit = kg)
Chain Weight for Span Calibration
10.0
0.1~1000.0g/m
([P107] Scale Unit = g)
P112
HAng
Hanging Weight
0.1~1000.0kg
([P107] Scale Unit = kg)
Hanging Weight for Span Calibration
10.0
0.1~1000.0g
([P107] Scale Unit = g)
P113
SCLL
Weigh Length
0.001~50.000m
1.000
P114
CALI
Calibration Current
4.00~20.00mA
Control Current for System Calibration
12.00
P115
-Zt-
Zero Tracking
Permission
0: OFF; 1: ON
0
P116
-tr-
Zero Tracking Range
±(0~10%) × [P302] Flow Range
±5%
P117
-ZA-
Zero Adjusting Range
±(0~10%) × [P104] Zero Value
±5%
P118
-Zr-
Zero Refresh
0: RAM (Only Refresh RAM Zero Value)
1: FLASH/RAM (Refresh Original Zero
Value)
0
P119
-SP1
Breakpoint1
0~[P120] (AD Value: 0~60000)
Breakpoint1 of Segmenting Span
Correction
18000
P120
-SP2
Breakpoint2
[P119]~Max. AD Value (60000)
Breakpoint2 of Segmenting Span
Correction
42000
P121
-C1-
Span Correction
Coefficient 1
0.500~2.000; Span Correction Coefficient
of AD Value Linear Segment 1: 0~[P119]
1.000
P122
-C2-
Span Correction
Coefficient 2
0.500~2.000; Span Correction Coefficient
of AD Value Linear Segment 2:
[P119]~[P120]
1.000
P123
-C3-
Span Correction
Coefficient 3
0.500~2.000; Span Correction Coefficient
of AD Value Linear Segment 3:
[P120~Max. AD Value
1.000
P124
CAdd
Totalizing While
Calibrating
0: OFF
1: ON [In the process of „Load
Calibration‟, the inputted actual weight
value will be added to Totalized Weight]
0
P125
nAdd
Negative Totalizing
0: OFF [The negative variance
of Totalized Weight will be ignored]
1: ON
1
